GACIRON W01 Bike Outdoor Highway Intelligent Tail Lights

Brand: GACIRON

Product: Smart Bike taillight

Model: W01

Color: Red + Black

Taillight Battery: 1000mAh 3.7V lithium battery (host) is greater than 48 hours (flash mode) (not included)

Remote Control Battery: 200mAh 3V 2032 button batteries (remote control) (not included)

Features:

Viewing angle: greater than 220 degrees

Night shift discernable distance: about 30-50m

Vehicle detection range: about 50-100m

Remote control distance: more than 10 m

Application: riding

Remote (mm): 60 (D) x 30 (H)

Dimensions (mm): 103 (L) x 60 (W) x 55 (H)

Packing size (mm): 156 (L) x 125 (W) x 75 (H)

Weight (g): 215/370

Accessories: Smart bicycle taillights, intelligent taillight bracket, remote control, remote control holder, MiniUSB power cable, manual, warranty card, certificate.


Instructions:

Host computer
Power off
Short press the power button has 5 modes: fast flashing red lights, slow flashing red lights, lit red lights, double flashing (about yellow lights flashing), shut down. Buzzer voice prompts mode switch on and off.

Function

Left and right turn: respectively the left and right yellow flashing:
Uniform riding: By manually select 4 way light (fast flashing red lights, slow flashing red lights, lit red lights, double flashing) (left yellow lights flashing).

Brakes: acceleration sensor automatically senses the brake, the red light was significantly higher than the uniform riding brightness.

LED power indicator 1:
                              1 Charging indicator: Work indicator LED flashes charged lamp;
                              (2) Low Battery Alert: When the battery voltage falls below 15%, the charging indicator light flashes, prompting the user to recharge.

Remote control:
          1 right: Toggle shift lever upwards, so right tail light flashes while the right direction on the remote control flashes;
          2 Left Turn: Turn steering lever down, so that left taillight lamp flashes, while left arrow on the remote flashes
          3 bell: bell next key ringing warning.
Pairing the remote control:
          * Long press on the lamp mode switching button for 3 seconds, the working indicator flash, enter pairing mode.
          * Remote control lever hit the left direction, long press hold the bell button.
          * Buzzer voice prompts, and the left turn signal flashing, remote control and main unit's remote pairing process is complete.
