Fenix HP20 High Intensity and Anti-freezing 230 LM XP-G R5 LED Headlamp

Brand Name:Fenix

Model No:HP20

Max Output: 230 lumens.

Impact resistance: 1.5m

Color: Black+Yellow

LED: Cree XP-G LED (R5) with a lifespan of 50,000 hours

Battery: 4 x 1.5V AA battery (not include)

Waterproof: Accord to IPX-8 standard.

Head Size(mm): 70(L) x57(W)x56(H)

Battery Case(mm):108(L)x79(W)x30(H)

Weight(g):333/578

Separate design makes it more balanced and comfortable

Drive-by-wire bi-switch for simple and fast operation

LED housing made of durable aircraft-grade aluminum

Headlamp structure made of high quality plastic

Toughened ultra-clear double glass lens with anti-reflective coating

Output Modes

Turbo: 230 lumens, 3 hours 29 mintues

High: 125 lumens, 8 hours 24 minutes

Mid: 51 lumens, 24 hours

Low: 6 lumens, 296 hours

Strobe: 230 lumens

Slow flash: 51 lumens

SOS: 51 lumens

Operation:

The button in the battery case is the main switch for turning the headlamp on and off. The yellow button in the drive-by-wire switch is a standby switch. The blue button is a dimmer switch.

Depress the main switch for one click to turn on the headlamp and lock it. Depress the switch again to turn off the headlamp. When the headlamp is on, depress the standby switch to turn off the headlamp temporarily. Another depress will activate the headlamp again.

When the headlamp is on, double-press the standby switch quickly to switch to the flashing modes. Depressing the switch then will shift between the different outputs. The output sequence is as follows:

    Turbo > Low > Medium > High > Cycle.

In the flashing mode, depress the dimmer switch to shift between flashing modes:

    Strobe > Rescue Signal > Slow Flash > Cycle.

The HP20 will memorize the mode it's on when it is turned off.

If the HP20 will not be used for awhile, please depress the main button to fully turn off the power.
